Product Technical Parameters | |||
1 | Model Name | / | 9QS-4500S Self-propelled Green Forage Harvester |
2 | form | / | Self-propelled |
3 | Working state dimensions (length x width x height) | mm | 7920X4650X6000 |
4 | Matching engine rated power | kW | 390 |
5 | Matching engine rated speed | r/min | 1900 |
6 | Cutting width | mm | 4450 |
7 | Crop collecting header type | / | Straight cutting table |
8 | Header cutter type | / | Disc cutter |
9 | Feeding mechanism type | / | Feeding roller |
10 | Number of feeding mechanisms | indivual | 4 |
11 | Straw chopping mechanism type | / | Drum type |
12 | Grain crushing mechanism type | / | Roller type |
13 | Speed Shift | / | Manual speed shift |
14 | Drive mode | / | Hydraulic drive |
15 | Brake type | / | Disc |
16 | Steering wheel track | mm | 2505 |
17 | Guide wheel tire specifications | / | 19.5L-24 |
18 | Driving wheel track | mm | 2570 |
19 | Driving wheel tire specifications | / | 800/65R32 |
20 | Wheelbase | mm | 2860 |
twenty one | Designed cutting length | mm | 1st gear: short 6; long 82nd gear: short 11; long 143rd gear: short 18; long 22 |
